Thor Motor Coach Windsport Motor Home Class A

Previous
Next
1 of 49

The Windsport Class A gas motor home by Thor Motor Coach is made to fit your endeavors. There is something for everyone to be able to have fun along the way and at the final destination. The Windsport starts with a Ford F-53 chassis and Triton 320 HP engine. You will also find one-piece fiberglass front and rear caps, automatic leveling jacks with touchpad controls, and an 8,000 lb. trailer hitch with 7-pin round connector, plus a HD-MAX exterior with graphics package including partial-paint. Yet we haven't even mentioned all the interior features that you are sure to want!


You can easily see with the Windsport Class A that nothing else will quite measure up in comfort, quality and value. Let the wind take you along many adventures beginning today in a Windsport Class A gas motor home by Thor Motor Coach!

  • Windsport 27B

    Windsport 27B Floorplan Image

    Thor Motor Coach Windsport class A gas coach 27B highlights: King Denver ... more about Windsport 27B

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 2
    Length 29 ft 3 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Mystic Moon, Winter White
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 18000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 40 gals
    Tire Size 19.5"
    Furnace BTU 30000 btu
    Generator Onan RV QG 4000 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 190 in
    Number Of Bunks 1
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Double Door
    Cooktop Burners 3
    Shower Size 24" x 36" in
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    Basement Storage 73 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 18' Legless Lateral Power Awning with Integrated LED Lighting
    Gross Combined Weight 23000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Windsport 29M

    Windsport 29M Floorplan Image

    Thor Motor Coach Windsport class A gas coach 29M highlights: Full Wall Slide ... more about Windsport 29M

    Specifications

    Sleeps 7
    Slides 1
    Length 30 ft 8 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Mystic Moon, Winter White
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 18000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 40 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 4000 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 190 in
    Number Of Bunks 1
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Double Door
    Cooktop Burners 3
    Shower Size 24" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    Basement Storage 64 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 18' Power Legless Lateral w/ Integrated LED Lighting
    Gross Combined Weight 23000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Windsport 31S

    Windsport 31S Floorplan Image

    Thor Motor Coach Windsport class A gasoline 31S highlights: Queen Denver ... more about Windsport 31S

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 2
    Length 31 ft 6 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Fusion Grey II, Golden Mink II
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 18000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 44 gals
    Black Water Capacity 24.5 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 4000 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 190 in
    Number Of Bunks 1
    Available Beds Queen
    Torque 460 ft-lb
    Refrigerator Type Double Door
    Cooktop Burners 3
    Shower Size 30" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    Basement Storage 67 cu. ft.
    TV Info LR 32" LED, BR 32" LED, Ext. 32" LED
    Awning Info 18' Power Legless Lateral w/ Integrated LED Lighting
    Gross Combined Weight 23000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Windsport 31Z

    Windsport 31Z Floorplan Image

    Thor Motor Coach Windsport class A gasoline 31Z highlights: Queen Denver ... more about Windsport 31Z

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 2
    Length 32 ft 9 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Fusion Grey II, Golden Mink II
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 18000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 47 gals
    Black Water Capacity 26 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 4000 Gas
    Fuel Type Gasoline
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 208 in
    Number Of Bunks 1
    Available Beds Queen
    Torque 460 ft-lb
    Refrigerator Type Double Door
    Cooktop Burners 3
    Shower Size 24" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    Basement Storage 143 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 16'6" Power Legless Lateral w/ Integrated LED Lighting
    Gross Combined Weight 23000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Windsport 34J

    Windsport 34J Floorplan Image

    Thor Motor Coach Windsport class A gas coach 34J highlights: Bunk Beds King ... more about Windsport 34J

    Specifications

    Sleeps 9
    Slides 1
    Length 35 ft 7 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Mystic Moon, Winter White
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 22000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 40 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 5500 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 242 in
    Number Of Bunks 3
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Residential w/Ice Maker
    Refrigerator Size 11 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 27000 btu
    Basement Storage 116 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Bunk Area 15.5" & 24" LED, Ext. 32" LED
    Awning Info 18' Power Legless Lateral w/ Integrated LED Lighting
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Windsport 34P

    Windsport 34P Floorplan Image

    Thor Motor Coach Windsport class A gasoline 34P highlights: King Denver Mattress ... more about Windsport 34P

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 2
    Length 36 ft
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Fusion Grey II, Golden Mink II
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 22000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 40 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 5500 Gas
    Fuel Type Gasoline
    Engine Triton 6.8L V10
    Chassis Ford F53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 242 in
    Number Of Bunks 1
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Residential w/Ice Maker
    Refrigerator Size 11 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 27000 btu
    Basement Storage 105 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 20' Power Legless Lateral w/ Integrated LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Windsport 34R

    Windsport 34R Floorplan Image

    Thor Motor Coach Windsport class A gas coach 34R highlights: Theater Seating ... more about Windsport 34R

    Specifications

    Sleeps 8
    Slides 2
    Length 36 ft
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Mystic Moon, Winter White
    Exterior Color Bahama Breeze or Oceanside Full Body Paint on HD-MAX or Dockside, Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 22000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 40 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 5500 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 242 in
    Number Of Bunks 1
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Residential w/Ice Maker
    Refrigerator Size 11 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 27000 btu
    Basement Storage 109 cu. ft.
    TV Info LR 50" LED & 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 18' Power Legless Lateral w/ Integrated LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Windsport 35M

    Windsport 35M Floorplan Image

    Thor Motor Coach Windsport class A gas coach 35M highlights: Bath and a Half ... more about Windsport 35M

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 2
    Length 36 ft 9 in
    Ext Width 8 ft 3 in
    Ext Height 12 ft 2 in
    Int Height 7 ft
    Interior Color Etched Nickel, Mystic Moon, Winter White
    Exterior Color Bahama Breeze and Oceanside on HD-MAX, Dockside and Waterfront Partial Paint on HD-MAX
    Hitch Weight 8000 lbs
    Gross Weight 22000 lbs
    Fresh Water Capacity 50 gals
    Grey Water Capacity 79 gals
    Black Water Capacity 79 gals
    Tire Size 19.5"
    Furnace BTU 35000 btu
    Generator Onan RV QG 5500 Gas
    Fuel Type Gas
    Engine Triton 6.8L V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 242 in
    Number Of Bunks 1
    Available Beds King
    Torque 460 ft-lb
    Refrigerator Type Residential w/Ice Maker
    Refrigerator Size 11 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36" in
    Number of Awnings 1
    LP Tank Capacity 88 lbs.
    Water Heater Capacity 6 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 27000 btu
    Basement Storage 112 cu. ft.
    TV Info LR 40" LED, BR 32" LED, Ext. 32" LED
    Awning Info 18' Power Legless Lateral w/ Integrated LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

Windsport Features:

Standard Features (2019)



Construction & Exterior

  • Ford® F-53 Chassis - 6.8L Triton® V10 Engine, 320HP, 460 lb.-ft. Torque
  • 8,000-lb. Trailer Hitch with 7-pin Round Connector
  • Automatic Leveling Jacks with Touchpad Controls
  • Welded Tubular Steel Floor
  • Welded Tubular Aluminum Roof and Sidewall Cage Construction
  • Vacu-Bond Laminated Roof, Walls & Floor with Block Foam Insulation
  • One-Piece Fiberglass Front and Rear Caps
  • One-Piece Windshield
  • HD-MAX® Exterior with Graphics Package
  • Rotocast Storage Compartments
  • Side-Hinged Flush Mount Radius Compartment Doors
  • Premium One-Piece TPO roof
  • Legless Lateral Power Patio Awning with Integrated LED Lighting
  • Power Entry Door Awning (34R)
  • Slide Out Topper Awning(s)
  • Roof Ladder
  • Electric Entry Step
  • Entry Door with Dead Bolt Lock
  • Exterior Grab Bar Handle
  • Frameless Windows
  • Petlink Multi-Purpose Tie Down

Construction & Exterior Options

  • Partial Paint on HD-MAX® Exterior with Graphics Package
  • Frameless Dual Pane Windows

Automotive & Cockpit

  • 10" Touchscreen Dash Radio with Bluetooth with iGo primo Navigation
  • Heated/Remote Exterior Mirrors with Integrated Side View Cameras
  • Back-Up Monitor
  • Cruise Control
  • Tilt Steering Wheel
  • Privacy Curtain on Side Windows
  • Power Privacy Shade and Sunvisor at Windshield
  • Map Lights
  • Dash Fans
  • Drink Holders
  • Stow Away Coffee Table
  • Dash Workstation with 110-volt & 12-volt Outlets
  • Generator Start Switch on Dash
  • Emergency Engine Start Switch
  • Three-Point Seatbelts for Driver and Passenger
  • Reclining/Swivel Leatherette Captain's Chairs
  • Power Drop-Down Hide-Away Overhead Bunk with Cotton Cloud™ Mattress & Bunk Ladder
  • Conversation Mirrors in Front Overhead Cabinets
  • Power Driver's Seat
  • Fog Lights
  • 19.5" Tires w/ Stainless Steel Wheel Liners
  • Valve Stem Extenders on Rear Wheels

Interior

  • Rubber Tread Entry Steps with Lighted Step Well
  • Metal Entry Grab Handle
  • 84" Interior Ceiling Height
  • Residential Vinyl Flooring
  • Fire Extinguisher
  • Smoke, LPG, Carbon Monoxide Detectors
  • Ceiling Ducted Air Conditioning System
  • Raised Panel Upper Cabinet Doors with Nickel Finish Hardware & Glass Inserts on Select Doors
  • Full Extension Metal Ball-Bearing Drawer Guides
  • LED Lighting
  • Hard Vinyl Ceiling
  • Leatherette Expanding Sofa w/ Hide-a-Bed (35M)
  • Leatherette Sofa Bed (N/A 35M)
  • Leatherette "Theater Seats" with Integrated Footrests (34R)
  • Dream Dinette® Booth with Cup Holder
  • Dinette Storage Drawer (In Rear Facing Dinette) (N/A 29M)
  • Passenger Seatbelts in Select Areas
  • Window Privacy Shades

Interior Option

  • Single Child Safety Tether in Dinette

Kitchen

  • Double Door Refrigerator (27B, 29M)
  • 11 cu. ft. Residential Refrigerator with Ice Maker (34J, 34R, 35M)
  • 3-Burner Gas Cooktop/Oven with Bi-Fold Glass Cover
  • 30” Over-the-Range Microwave Oven
  • Solid Surface Countertops & Pressed Laminate Dinette Countertop
  • Decorative Glass & Tile Backsplash
  • Large Double Bowl Sink with Single Handle Faucet & Pull-Down Sprayer
  • Pantry (27B, 34J, 35M)
  • Ball Bearing Drawer Guides
  • 12-volt Attic Fan with Cover

Bedroom & Bathroom

  • Denver Mattress® King Size Bed
  • Bedroom 12V Outlet for CPAP Machine
  • Bedroom 110V Outlet on Inverter for CPAP Machine (N/A 27B, 29M)
  • Bunk Beds in Hallway Slide Out (34J)
  • Foot Flush Porcelain Toilet
  • Skylight in Shower
  • Shower with Glass Door

Bedroom & Bathroom Option

  • 12-volt Attic Fan with Cover in Bedroom (27B & 29M Only) (N/A on 29M when Dual 13,500 BTU Roof Air Conditioners are Optioned)

Entertainment

  • 40” LED TV in Living Room
  • 50" LED TV in Living Room (34R)
  • 32" LED TV in Bedroom
  • Exterior 32” LED TV on Swivel Bracket, Soundbar & Radio
  • Blu-Ray Player in Living Area
  • 15.5” & 24” LED TVs & DVD Player in Bunk Bed Area (34J)
  • HDMI Video Distribution
  • Satellite Dish Ready
  • Cable TV Ready
  • Digital TV Antenna
  • Exterior Kitchen with 2.6 cu. ft. Refrigerator & Sink (29M, 34J)
  • Exterior LP Connection
  • Power Charging Center for Electronics
  • Speaker in Sofa Overhead

Electrical & Plumbing

  • Onan RV QG 4000 Gas Generator (27B, 29M)
  • 30-amp Detachable Shoreline Power Cord (27B, 29M)
  • 50-amp Detachable Shoreline Power Cord, Dual 13,500 BTU Roof Air Conditioners, and Onan® RV QG 5500 Gas Generator (12-volt Attic Fan N/A on 29M when Optioned) (34J, 34R, 35M)
  • Second Auxiliary House Battery
  • Solar Charge Controller - Solar Panel Ready
  • Battery Tray that Holds up to Four Batteries (34J, 34R, 35M)
  • 15,000 BTU Front Roof Air Conditioner (27B, 29M)
  • Battery Disconnect Switch
  • 6-gallon DSI Gas/Electric Water Heater
  • Water Heater Bypass System
  • Enclosed & Heated Holding Tanks (N/A 29M)
  • Enclosed Holding Tanks with Heat Pads (29M)
  • Black Tank Flush System
  • Stackable Washer/Dryer Prep (34R, 35M)
  • Automatic Generator Start
  • 1800-watt Inverter (34J, 34R, 35M)
  • 1000-watt Inverter (27B, 29M)
  • Outside Shower
  • 360 Siphon RV Holding Tank Vent Cap
  • 1" Fresh Water Tank Drain
  • Multiplex Lighting and Systems Control
  • WIFI Ranger/WIFI Extender

Electrical & Plumbing Option

  • 50-amp Detachable Shoreline Power Cord, Dual 13,500 BTU Roof Air Conditioners, and Onan® RV QG 5500 Gas Generator (12-volt Attic Fan N/A on 29M when Optioned) (27B, 29M)



See us for a complete list of features and available options!



All standard features and specifications are subject to change.

Manu-Facts:

Thor Motor Coach (TMC) is the #1 Motorhome Brand in North America, producing nearly 1 out of every 4 motorhomes sold each year. Formed in 2010 as a strategic merger of Damon Motor Coach and Four Winds International, we build many of the world’s most recognized motorhomes. As an industry leader in introducing cutting­edge innovations, we offer a wide range of styles, sizes, floor plans and features – delivering coaches that fit every customer’s lifestyle and budget.

Our diverse product lineup includes many of the world’s most recognized gas­ and diesel­ powered Class A and Class C motorhomes, including the Four Winds, Challenger, Chateau, ACE and Tuscany models. By building a variety of unique styles, sizes and floor plans, we offer motorhomes that feel custom ­made – at a truly competitive price.

With so many unique models available, TMC motorhomes are priced to fit anyone’s budget – from families buying their first motorhome, to full­timers looking for a roaming “dream home.” No matter how you choose to spend your time or your money, there’s a TMC motorhome that fits your needs.
Byerly RV 295 E. 5th Street Eureka, MO 63025 636-938-2000
Copyright © 2018 Byerly RV • RV Dealer Website DesignPrivacy PolicySold RVs
