Keystone RV Retreat Destination Trailer

Previous
Next
1 of 39

The Keystone Retreat destination travel trailer provides you with a luxury you'll love, and value you can live with. Imagine taking a vacation that requires less preparation, packing, and planning. Keystone can bring you great at-home features in a standard model or a luxury package model. Each model features a 102" wide body construction, fiberglass front cap, 8' tall ceilings, central vacuum system, residential high end furniture, a residential patio door with screen door, and a detachable hitch to name a few.


No matter which model you choose, the Keystone Retreat is your ultimate freedom vehicle. Pick your destination travel trailer and retreat into a place of rest and relaxation today!
  • Retreat 39FDEN

    Retreat 39FDEN Floorplan Image

    Keystone Retreat destination trailer 39FDEN highlights: 19 Ft. Vaulted Slide ... more about Retreat 39FDEN

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 2
    Length 40 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 7 in
    Int Height 8 ft
    Interior Color Lodge, Timber
    Hitch Weight 1255 lbs
    Dry Weight 10590 lbs
    Cargo Weight 2610 lbs
    Fresh Water Capacity 53 gals
    Grey Water Capacity 78 gals
    Black Water Capacity 36 gals
    Tire Size ST235/80R16E
    Furnace BTU 42000 btu
    Available Beds King
    Refrigerator Type Residential
    Refrigerator Size 15 cu ft
    Cooktop Burners 3
    LP Tank Capacity 30 lbs.
    Water Heater Capacity 16 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    TV Info 40" HD LED TV Living Room
    Axle Count 2
    Number of LP Tanks 2
    Shower Type Radius
    Electrical Service 50 amp

    Similar Floorplans

  • Retreat 39FKSS

    Retreat 39FKSS Floorplan Image

    Take a Virtual Tour

    Keystone Retreat destination trailer 39FKSS highlights: 19 Ft. Vaulted Slide ... more about Retreat 39FKSS

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 3
    Length 40 ft 2 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 7 in
    Int Height 8 ft
    Interior Color Lodge, Timber
    Hitch Weight 1380 lbs
    Dry Weight 10828 lbs
    Cargo Weight 2522 lbs
    Fresh Water Capacity 53 gals
    Grey Water Capacity 78 gals
    Black Water Capacity 39 gals
    Tire Size ST235/80R16E
    Furnace BTU 42000 btu
    Available Beds King
    Refrigerator Type Residential
    Refrigerator Size 15 cu ft
    Cooktop Burners 3
    LP Tank Capacity 30 lbs.
    Water Heater Capacity 16 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    TV Info 40" HD LED TV Living Room
    Axle Count 2
    Washer/Dryer Available Yes
    Number of LP Tanks 2
    Shower Type Neo-Angled
    Electrical Service 50 amp

    Similar Floorplans

  • Retreat 39MKTS

    Retreat 39MKTS Floorplan Image

    Take a Virtual Tour

    Keystone RV Retreat destination trailer 39MKTS highlights: Large Wardrobe ... more about Retreat 39MKTS

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 3
    Length 40 ft 8 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 7 in
    Int Height 8 ft
    Interior Color Lodge, Timber
    Hitch Weight 1890 lbs
    Dry Weight 11718 lbs
    Cargo Weight 2197 lbs
    Fresh Water Capacity 53 gals
    Grey Water Capacity 71 gals
    Black Water Capacity 39 gals
    Tire Size ST235/80R16E
    Furnace BTU 42000 btu
    Available Beds King
    Refrigerator Type Residential
    Refrigerator Size 15 cu ft
    Cooktop Burners 3
    LP Tank Capacity 30 lbs.
    Water Heater Capacity 16 gal.
    Water Heater Type DSI Gas/Electric
    AC BTU 15000 btu
    TV Info 50" HD LED TV Living Room
    Axle Count 2
    Washer/Dryer Available Yes
    Number of LP Tanks 2
    Shower Type Neo-Angled
    Electrical Service 50 amp

    Similar Floorplans

Retreat Features:

Standard Features

Living Room Highlights
  • 8 ft. Ceiling Height
  • 19 ft. Slide Room with Cathedral Ceiling on FDEN & FKSS
  • Decorative Plantation Blinds in Living Area
  • Fireplace
  • 50" HD LED TV (39MKTS, 39LOFT, 39RLTS)
  • DVD/AM/FM/CD/MP3 Stereo System with Bluetooth
  • Recliner (39FDEN, 39FKSS only)
  • Residential Recessed Ceiling Lighting
  • Wall Sconce in Slide Room
  • Dinette Chandelier
  • Solid Wood Slide Room Facia
  • 39 in. Main Slide Room Depth
  • 72" Tri-Fold Sleeper Sofa
  • 40" HD LED TV (Except 39MKTS, 39FDEN, 39LOFT)
  • Theatre SEating (39MKTS, 39FDEN, 39LOFT)
  • 12 Volt Charging Station
  • Free Standing Dinette with Four Chais
  • Ceiling Fan with Light (39FDEN & 39FKSS only)
  • Etched Glass Overheads
Kitchen Highlights
  • Extra large double bowl kitchen sink
  • Residential “eat in” bar (FKSS, FDEN)
  • Solid Wood Raised Residential Panel Cabinets with Crown Molding
  • Residential Ball Bearing Drawer Guides
  • Three Burner Range with Oven
  • Double Door Pantry
  • Upgrade Central Vacuum System
  • High Rise Faucet with Pull Out Sprayer
  • Waste Basket Storage
  • Pre-Drilled and Screwed Solid Cabinet Stiles
  • Microwave and Carousel
  • 15 cu. ft. Residential Black Refrigerator
  • Residential Water Purification System
  • Two Bar Stools (FKSS, FDEN)

Bath

  • Porcelain Toilet with Foot Flush
  • Fantastic Fan w/Convenient Wall Mount control (N/A 39LOFT)
  • Washer and Dryer Prep (N/A 39BHTS, 39BHQS, 39FDEN)
  • Dressing Mirror
  • Neo-Angle Glass Shower with Surround
  • Large Medicine Cabinet
  • Louvered Door on Large Closet

Bedroom

  • 7 ft. Tall Bed Slide
  • Mega Storage Under Master Beds
  • Two Door Wardrobe
  • Pleated Shades
  • Residential Ceiling Fan
  • Prep for 2nd TV
  • Six Panel Interior Bedroom Doors
  • Pillow Top King Mattress
  • Etched Glass Cabinet Doors in the Bed Slide
  • Fully Extendable Deep Dresser Drawers
  • Large Panoramic Window Recessed Decorative Lighting
  • Oversized Bed Slide w/Overhead Cabinets, Accented w/Decorative Cabinet Doors & Functional Reading Lights
  • Gas Strut Assisted Bed Lift

Exterior

  • Fiberglass Front
  • Dual 30 lb. LP Bottles with Automatic Change Over & Cover
  • 2 Exterior Shower
  • Satellite / Cabel TV Hook-Up
  • 110 Volt Exterior Outlets
  • Residential Exterior Soffit Lights
  • Large Swing Away Grab Handle
  • Residential Patio Door with Screen Door
  • 50 Amp Detachable Power Cord
  • E-Coated Wheels

Mechanics

  • 16 Gallon Gas/Electric DSI Water Heater
  • 15,000 BTU Ducted Air Conditioner
  • 50 Amp Electric Service w/Detachable Cord
  • 110 Volt Outlets in the Slides
  • 42,000 BTU Furnace
  • Prepped for a Second Air Conditioner
  • 75 Amp Converter
  • 12 Volt SHURflo Water Pump

Construction

  • 12 in. Powder Coated I-Beam Frame
  • 5/8 in. Seamless Dyna Span Floor Decking w/Limited Lifetime Warranty
  • Laminated Veneer Lumber Slideout Reinforcements
  • Radius Corner Blocks Around Window and Compartment Doors
  • Super Frame Reinforced Frame
  • Darco Wrapped Main Floor Vapor Moisture Barrier
  • 2 in. Wall Studs Constructed 16 in. on Center
  • 4 1/2 in. Crowned Roof
  • Reinforced Slide Room Openings
  • Metal Floor Registers

Safety

  • Safety Chains
  • Electric Brakes on All Wheels
  • LP Gas Detector
  • GFI Electrical Outlets
  • Break Away Switch
  • Carbon Monoxide Detector
  • Smoke Detector
  • Tinted Safety Glass Windows
Unique Retreat Features
  • Large Bay Windows with Decorative Exterior Front
  • 102" Wide Body Construction
  • Vaulted 19 ft. Slide Out Rooms (39FDEN & 39FKSS)
  • King Bed Standard
  • Black Tank Flush
  • 8 ft. Tall Ceilings
  • Detachable Hitch
  • Residential High End Furniture
  • “Eat in Bar” in Every Kitchen (N/A 39BHTS, 39BHQS, 39MKTS)
  • Central Vacuum System
Luxury Package (Optional)
  • Champagne Laminated Sidewalls
  • Solid Surface Counter Tops
  • Chefs Gourmet Faucet
  • Stainless Steel Appliance Package
  • Upgraded Graphics Package
  • Stainless Steel Under Mount Sink
  • Upgraded interior Lighting Package
  • Heated & Enclosed Underbelly

Options

  • Electric Patio Awning
  • Stabilizer Jacks
  • 2nd 13.5K BTU A/C
  • Dual Pane Windows (Only Available with Luxury Package)

See us for a complete list of features & available options!

All standard features and specifications are subject to change.

Manu-Facts:



At Keystone we do things differently, and have since we first opened our doors in 1996. This different way means focusing on you, our customer, and building RVs that are much more than great floor plans and prices. It starts with innovative products that are built tough, and doesn’t stop there. It’s our commitment to provide a better ownership experience. We understand that when you put your hard earned money down, you expect your RV to deliver as promised. That’s why “Building Adventures for the Long Haul” is more than just a slogan here at Keystone; it is our number one mission each and every day. It’s the reason today we are honored to say we have nearly one million Keystone owners out on the open road who we consider family.
